A set of professional CAD and modeling tools made for designers, innovators and engineers. Without compromise.

Our latest release adds to and improves the tools and features you love, as well as new functionality and UI to supercharge your productivity.

New in V24.2 highlights
Consistent control of custom paper sizes for Print & Publish output
Pro / Lite
ENHANCED
Print & Publish output

BricsCAD supports custom printer paper sizes to ensure consistent print and publish outputs.

Improved layout preview generation in Sheet Set Manager
Pro / Lite
ENHANCED
Sheet Set Manager

We have improved the import performance of existing drawing layouts into a new sheet.

Status bar indication of hidden entities in the current drawing
Pro / Lite
NEW
HIDEOBJECTS – on the Status Bar

The presence of hidden or isolated objects in a drawing is now directly indicated on BricsCAD’s Status Bar.

UI access to nested purge functionality
Pro / Lite
NEW
Nested PURGE – UI access

Nested PURGE operations are now selectable from the Purge dialog, either in standalone mode, or through the Drawing Health Manager.

FINDOUTLIERS
Pro / Lite
ENHANCED
FINDOUTLIERS

BricsCAD’s unique FINDOUTLIERS workflow now performs better on drawings with large extants. There is also an improved user interface for better usability – including the ability to draw a valid area, a 2D/3D mode toggle, and new icon symbology for invisible, frozen and hidden outliers.

Option to save converted blocks to Library folders
Pro / Lite
NEW
Block Libraries

Converted Parametric Blocks can now automatically be saved to block Libraries.

Improved UX during Direct Modeling operations
Pro / Lite
NEW
Direct Modeling
