Blender Plumber 1.0.1 – Source Engine Importer 2024 Download
A Blender addon for importing Source 1 engine maps, models, materials and textures.
This addon makes it possible to import full CS:GO, TF2, CS:S or other Source 1 game maps into Blender. Source 2 games, such as CS2, are not supported. The imported maps have accurate materials and overlays and correctly placed props and lights. Skyboxes are converted into a Blender-compatible format and 3D skyboxes can be easily transformed into the correct position and scale with minimal user intervention. No manual game file extraction is required and installed Source games on Steam are detected automatically. You just need to select the correct game and start importing.
Supported file types are .vmf, .mdl, .vmt and .vtf. For a more complete overview of supported features, see Supported features for imported assets.
Import dialog
Table of contents
Requirements
Quick start
Installation
Installing latest from source (very advanced users)
Usage
Detecting new Steam games
Importing from old CS:GO installation
Common import options
Maps
MDL
Materials
Textures
Game file browser
Troubleshooting
Credits
License
Requirements
OS: Windows recommended. Linux and macOS supported. M1 Macs not supported.
Blender: 2.90 or newer (tested up to 4.0).
Quick start
Make sure you are using Blender 2.90 or newer.
Install the latest release of this addon and enable it.
Open the Blender console to get progress updates and start importing from the File -> Import -> Plumber menu.
Installation
You can also follow a video tutorial, such as this one by ItsJustChris. This tutorial is recorded using a beta version, but also applies to the current version.
Make sure you are using Blender 2.90 or newer.
Download the latest addon release from the releases tab. Make sure you download a file starting with plumber-v1.x.x, not the source code. Also make sure that you downloaded the correct version for your operating system.
Do not extract the downloaded files.
Open Blender and install the addon: Install addon
Installing latest from source (very advanced users)
Make sure the following dependencies for building the addon are installed. The links are for Windows, for other platforms you need to figure it out yourself.
Python 3 with “Add python to environment variables” selected in the installer
Git with “Git from the command line and also from 3rd-party software” selected in the installer
Rust language and the latest stable compiler
Microsoft C++ Build Tools with “C++ MFC for latest build tools (x86 & x64)” selected in the installer under individual components.
CMake
After installing the dependencies, follow the following steps:
Download the repository as a .zip from the green “Code” button in the top right corner and extract it somewhere (or alternatively, clone it).
Run pip install -r requirements-dev.txt on a terminal.
Run python setup.py bdist_blender_addon.
The built addon will be in the dist directory.
Usage
Installed Steam games are automatically detected on the first addon startup. You can start importing immediately without any configuration required. Just remember to select the correct game when importing files.
